KINCO MK070E-32DX MK Series 7-inch HMI PLC All-in-One Controller
- Brand
- KINCO
- Model
- MK070E-32DX
- GEARWELL SKU
- GWP-000023805
- Category
- HMIs & Industrial PCs
Key specifications
- Display
- 7" TFT, 800 x 480, 256K colours
- Ethernet
- 10/100 Mbit/s
- PLC supply
- 24 V DC (20.4-28.8 V DC)
- Digital inputs
- 16 (NPN/PNP)
- Program memory
- max. 4k instructions (KincoBuilder)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO MK070E-32DX MK Series 7-inch HMI PLC All-in-One Controller |
|---|---|
| Brand | KINCO |
| Model | MK070E-32DX |
| Category | HMIs & Industrial PCs |
| Display | 7" TFT, 800 x 480, 256K colours |
| Ethernet | 10/100 Mbit/s |
| PLC supply | 24 V DC (20.4-28.8 V DC) |
| Digital inputs | 16 (NPN/PNP) |
| Program memory | max. 4k instructions (KincoBuilder) |
| Digital outputs | 4 transistor (PNP) + 12 relay |
| Dimensions / cut-out | 204 x 150 x 33.9 mm / 192 x 138 mm |
