KINCO MK043E-20DT MK Series 4.3-inch HMI PLC All-in-One Controller
- Brand
- KINCO
- Model
- MK043E-20DT
- GEARWELL SKU
- GWP-000023802
- Category
- HMIs & Industrial PCs
Key specifications
- Display
- 4.3" TFT, 480 x 272, 256K colours
- Ethernet
- 10/100 Mbit/s
- PLC supply
- 24 V DC (20.4-28.8 V DC)
- Analog inputs
- 2, 12-bit, 0-10 V
- Digital inputs
- 9 (NPN/PNP)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO MK043E-20DT MK Series 4.3-inch HMI PLC All-in-One Controller |
|---|---|
| Brand | KINCO |
| Model | MK043E-20DT |
| Category | HMIs & Industrial PCs |
| Display | 4.3" TFT, 480 x 272, 256K colours |
| Ethernet | 10/100 Mbit/s |
| PLC supply | 24 V DC (20.4-28.8 V DC) |
| Analog inputs | 2, 12-bit, 0-10 V |
| Digital inputs | 9 (NPN/PNP) |
| Program memory | max. 4k instructions (KincoBuilder) |
| Digital outputs | 9 transistor (PNP) |
| Dimensions / cut-out | 132 x 102 x 31.5 mm / 119 x 93 mm |
