KINCO GL2070HE-4G GL2 Green Series 7" HMI Touch Panel
- Brand
- KINCO
- Model
- GL2070HE-4G
- GEARWELL SKU
- GWP-000024038
- Category
- HMIs & Industrial PCs
Key specifications
- 4G
- LTE-FDD Band 1/3/5/8, LTE-TDD Band 34/38/39/40/41
- Display
- 7 in TFT, 16.7 million colours
- Network
- Ethernet + 4G
- Resolution
- 1024 x 600 px
- Input power
- DC 10.8-28 V, 4.2 W @ 24 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO GL2070HE-4G GL2 Green Series 7" HMI Touch Panel |
|---|---|
| Brand | KINCO |
| Model | GL2070HE-4G |
| Category | HMIs & Industrial PCs |
| 4G | LTE-FDD Band 1/3/5/8, LTE-TDD Band 34/38/39/40/41 |
| Display | 7 in TFT, 16.7 million colours |
| Network | Ethernet + 4G |
| Resolution | 1024 x 600 px |
| Input power | DC 10.8-28 V, 4.2 W @ 24 V DC |
| Touch panel | 4-wire resistive |
| Serial ports | COM0 RS232/RS485/RS422; COM1 RS485; COM2 RS232 |
| Dimensions / cut-out | 204 x 150 x 37 / 192 x 138 mm |
