KINCO GL104 Green Series GL 10.4-inch HMI Touch Panel
- Brand
- KINCO
- Model
- GL104
- GEARWELL SKU
- GWP-000023784
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- ARM RISC 32-bit 800 MHz
- Display
- 10.4" TFT, 800 x 600
- Brightness
- 350 cd/m2
- Input power
- DC 10.8-28 V, 8 W at 24 V DC
- Touch panel
- 4-wire resistive
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO GL104 Green Series GL 10.4-inch HMI Touch Panel |
|---|---|
| Brand | KINCO |
| Model | GL104 |
| Category | HMIs & Industrial PCs |
| CPU | ARM RISC 32-bit 800 MHz |
| Display | 10.4" TFT, 800 x 600 |
| Brightness | 350 cd/m2 |
| Input power | DC 10.8-28 V, 8 W at 24 V DC |
| Touch panel | 4-wire resistive |
| Serial ports | COM0 RS232/RS485/RS422; COM2 RS232 |
| Version options | GL104E (Ethernet) is the version in the official GL model list (specify on order) |
| Code suffix "(none)" | as collected; the official model-number list shows only GL104E |
| Dimensions / cut-out | 310 x 230 x 56 mm / 299 x 219 mm |
