KEYENCE MD-V9900 3-Axis YVO4 Laser Marker Standard Area
- Brand
- KEYENCE
- Model
- MD-V9900
- GEARWELL SKU
- GWP-000015645
- Category
- Test & Measurement
Key specifications
- Type
- Standard area, main unit (controller + marker)
- Laser
- YVO4, 1064 nm, Class 4
- Interface
- RS-232C / RS-422A / USB 2.0
- Scan speed
- Max. 12,000 mm/s
- Laser output
- 13 W (FDA version 8 W)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KEYENCE MD-V9900 3-Axis YVO4 Laser Marker Standard Area |
|---|---|
| Brand | KEYENCE |
| Model | MD-V9900 |
| Category | Test & Measurement |
| Type | Standard area, main unit (controller + marker) |
| Laser | YVO4, 1064 nm, Class 4 |
| Interface | RS-232C / RS-422A / USB 2.0 |
| Scan speed | Max. 12,000 mm/s |
| Laser output | 13 W (FDA version 8 W) |
| Power supply | 100 to 120 VAC or 200 to 240 VAC, 50/60 Hz |
| Marking space | 120 x 120 x 42 mm |
| Marking method | XYZ 3-axis simultaneous scanning |
| Reference work distance | 189 (±21) mm |
