JUMO 608425/2010-832-04-2000-251-100-105-26-150-10/410 Thermometer

Key specifications

Thread (105): Screw connection G 3/4
Material (26): Stainless steel (CrNi, 1.4571)
Code suffix "/410": as collected; not listed in the official model-number table
Capillary length: 2000 mm
Insertion length: 150 mm

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	JUMO 608425/2010-832-04-2000-251-100-105-26-150-10/410 Thermometer
Brand	JUMO
Model	608425/2010-832-04-2000-251-100-105-26-150-10/410
Category	Pressure, Flow & Temperature
Thread (105)	Screw connection G 3/4
Material (26)	Stainless steel (CrNi, 1.4571)
Code suffix "/410"	as collected; not listed in the official model-number table
Capillary length	2000 mm
Insertion length	150 mm
Capillary type (04)	FL04 stainless steel capillary (1.4571), diameter 2.2 mm
Display range (832)	-20 to +200 °C
Switching output (10)	Contact 1 (N/C) opens and contact 2 (N/O) closes, isolated electrical circuit (21)
Basic type extension (2010)	Design type 20; case size diameter 100 mm
Accuracy class according to DIN EN 13190	Class 1
Code suffix "251-100" (process connection / diameter positions)	as collected; not listed in the official model-number table
