INFRANOR CD1-pm Xtrapuls PROFIBUS Positioner Servo Drive
- Brand
- INFRANOR
- Model
- CD1-pm
- GEARWELL SKU
- GWP-000035375
- Category
- Servo Systems
Key specifications
- Evidence
- INFRANOR Xtrapuls CD1-pm installation manual, issue 8.15 (September 2020), infranor.com
- Fieldbus
- PROFIBUS DP (or stand-alone with digital I/O)
- Seller code
- CD1-PM (seller title: CD1-PM STO INFRANOR)
- Mains supply
- 230 VAC +10/-15 % 1~ or 3~ (230 V version); 400-480 VAC 3~ (400 V version), 50-60 Hz
- Rating options
- CD1-pm-230/2.25, /4.5, /7.5, /10.5, /16.5 or CD1-pm-400/1.8, /2.7, /5.1, /7.2, /14, /30, /45, /70, /90 (specify on order)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | INFRANOR CD1-pm Xtrapuls PROFIBUS Positioner Servo Drive |
|---|---|
| Brand | INFRANOR |
| Model | CD1-pm |
| Category | Servo Systems |
| Evidence | INFRANOR Xtrapuls CD1-pm installation manual, issue 8.15 (September 2020), infranor.com |
| Fieldbus | PROFIBUS DP (or stand-alone with digital I/O) |
| Seller code | CD1-PM (seller title: CD1-PM STO INFRANOR) |
| Mains supply | 230 VAC +10/-15 % 1~ or 3~ (230 V version); 400-480 VAC 3~ (400 V version), 50-60 Hz |
| Rating options | CD1-pm-230/2.25, /4.5, /7.5, /10.5, /16.5 or CD1-pm-400/1.8, /2.7, /5.1, /7.2, /14, /30, /45, /70, /90 (specify on order) |
| Code suffix "STO" | as collected; not part of the CD1-pm type designation in the installation manual |
| Auxiliary supply | 24 VDC +/-15 %, 320 mA without brake |
| Motor brake control | max. 1.5 A at 24 VDC |
| Positioning sequences | 128 |
| PWM switching frequency | 8 kHz |
