IFM IIT208 Inductive sensor
- Brand
- IFM
- Model
- IIT208
- GEARWELL SKU
- GWP-000030008
- Category
- Proximity & Photoelectric Sensors
Key specifications
- EMC
- EN 61000-4-2 ESD: 4 kV CD / 8 kV AD; EN 61000-4-3 HF radiated: 10 V/m; EN 61000-4-4 Burst: 2 kV; EN 61000-4-6 HF conducted: 10 V; EN 55011: class B
- MTTF
- 1594 years
- Cable
- 10 m, PVC, Ø 4.9 mm; 3 x 0.34 mm²
- Weight
- 428.2 g
- Display
- Switching status: 1 x LED, yellow
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM IIT208 Inductive sensor |
|---|---|
| Brand | IFM |
| Model | IIT208 |
| Category | Proximity & Photoelectric Sensors |
| EMC | EN 61000-4-2 ESD: 4 kV CD / 8 kV AD; EN 61000-4-3 HF radiated: 10 V/m; EN 61000-4-4 Burst: 2 kV; EN 61000-4-6 HF conducted: 10 V; EN 55011: class B |
| MTTF | 1594 years |
| Cable | 10 m, PVC, Ø 4.9 mm; 3 x 0.34 mm² |
| Weight | 428.2 g |
| Display | Switching status: 1 x LED, yellow |
| Housing | Threaded type |
| Material | housing: stainless steel (1.4404 / 316L); sensing face: PEEK natural; LED window: PEI; lock nuts: stainless steel (1.4404 / 316L) |
| Mounting | non-flush mountable |
| Dimensions | M30 x 1.5 / L = 45 mm |
| Hysteresis | 3...15 % of Sr |
| Protection | IP 68; IP 69K |
| Application | Use in hygienic areas / regular cleaning processes |
| UL approval | Ta: 0...40 °C; Enclosure type: Type 1; voltage supply: Limited Voltage/Current; File number UL: E174191 |
| Pack quantity | 1 pcs. |
| Sensing range | 22 mm |
| Items supplied | lock nuts: 2 |
| Output function | normally open |
| Special feature | Increased sensing range |
| Protection class | II |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Electrical design | PNP |
| Operating voltage | 10...36 DC V |
| Operating distance | 0...17.82 mm |
| Switch-point drift | -10...10 % of Sr |
| Thread designation | M30 x 1.5 |
| Ambient temperature | 0...100 °C |
| Current consumption | 10; (24 V) mA |
| Overload protection | yes |
| Real sensing range Sr | 22 ± 10 % mm |
| Switching frequency DC | 100 Hz |
| Increased sensing range | yes |
| Short-circuit protection | yes |
| Reverse polarity protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Max. voltage drop switching output DC | 2.5 V |
| Permanent current rating of switching output DC | 100 mA |
