IFM IM0011 IM series Inductive sensor
- Brand
- IFM
- Model
- IM0011
- GEARWELL SKU
- GWP-000030012
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Dimensions
- 40 x 40 x 120 mm
- Protection
- IP 65
- Sensing range
- 15 mm
- Output function
- normally open / closed; (selectable)
- Operating voltage
- 20...250 AC/DC V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM IM0011 IM series Inductive sensor |
|---|---|
| Brand | IFM |
| Model | IM0011 |
| Category | Proximity & Photoelectric Sensors |
| Dimensions | 40 x 40 x 120 mm |
| Protection | IP 65 |
| Sensing range | 15 mm |
| Output function | normally open / closed; (selectable) |
| Operating voltage | 20...250 AC/DC V |
| Ambient temperature | -25...80 °C |
| Switching frequency AC | 20 Hz |
| Switching frequency DC | 55 Hz |
