IFM IG5716 Inductive Sensor
- Brand
- IFM
- Model
- IG5716
- GEARWELL SKU
- GWP-000003470
- Category
- Industrial Automation Parts
Key specifications
- Dimensions
- M18 x 1 / L = 40 mm
- Protection
- IP 67
- Product type
- Inductive sensor
- Sensing range
- 5 mm
- Output function
- normally open
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm IG5716 (IGC2005-ARKG/UP) is an inductive proximity sensor in an M18 x 1 threaded housing 40 mm long, for flush mounting. Its rated sensing range is 5 mm. The real sensing range is 5 mm ± 10% and the operating distance on steel is 0…4.05 mm. The PNP/NPN switching output is normally open, rated at 150 mA and up to 720 Hz on 10…36 V DC, with reverse polarity and short-circuit protection. On other metals the distance is reduced by ifm's correction factors: 0.7 for stainless steel, 0.4 for brass, 0.3 for aluminum and 0.2 for copper. The sensor has an orange PBT housing, connects through a 2 m PVC cable with 2 x 0.5 mm² conductors and is rated IP67 for -25…80 °C ambient. Two lock nuts are included.
Technical reference
| Product name | IFM IG5716 Inductive Sensor |
|---|---|
| Brand | IFM |
| Model | IG5716 |
| Category | Industrial Automation Parts |
| Dimensions | M18 x 1 / L = 40 mm |
| Protection | IP 67 |
| Product type | Inductive sensor |
| Sensing range | 5 mm |
| Output function | normally open |
| Electrical design | PNP/NPN |
| Operating voltage | 10...36 V DC |
| Ambient temperature | -25...80 °C |
