IFM E30122 Welding Adapter for Process Sensors
- Brand
- IFM
- Model
- E30122
- GEARWELL SKU
- GWP-000004284
- Category
- Industrial Automation Parts
Key specifications
- Weight
- 191.5 g
- Product type
- Welding adapter for process sensors
- Surface finish
- Ra < 0.4 µm / Rz = 4 µm
- Pressure rating
- 50 bar / 5 MPa
- Wetted material
- Stainless steel 316L / 1.4435
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm E30122 (WELDING ADAPT D50/G1) is a Ø 50 mm welding adapter with a G 1 Aseptoflex Vario internal thread for process sensors, recommended for wall thicknesses up to 3 mm. The wetted parts are stainless steel (1.4435 / 316L) with a surface roughness of Ra < 0.4 µm (Rz = 4 µm), and the sensor-to-adapter connection is rated to 50 bar (5 MPa). An EPDM O-ring (24 x 2 mm, E30054) is supplied; FKM and FCM-compliant EPDM O-rings and welding aids are available as options.
Technical reference
| Product name | IFM E30122 Welding Adapter for Process Sensors |
|---|---|
| Brand | IFM |
| Model | E30122 |
| Category | Industrial Automation Parts |
| Weight | 191.5 g |
| Product type | Welding adapter for process sensors |
| Surface finish | Ra < 0.4 µm / Rz = 4 µm |
| Pressure rating | 50 bar / 5 MPa |
| Wetted material | Stainless steel 316L / 1.4435 |
| Sensor connection | G1 female Aseptoflex Vario |
| Process connection | Welding adapter, 50 mm diameter |
| Recommended wall thickness | Up to 3 mm |
