IFM AC2464 AS-Interface CompactLine module
- Brand
- IFM
- Model
- AC2464
- GEARWELL SKU
- GWP-000029957
- Category
- PLCs & I/O
Key specifications
- EMC
- EN 61000-6-2; EN 62026-2; EN 50581
- MTTF
- 382 years
- Weight
- 301.5 g
- Display
- Switching status: LED, yellow I1...I4; Power: LED, green AS-i; errors: LED, red
- Housing
- rectangular
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM AC2464 AS-Interface CompactLine module |
|---|---|
| Brand | IFM |
| Model | AC2464 |
| Category | PLCs & I/O |
| EMC | EN 61000-6-2; EN 62026-2; EN 50581 |
| MTTF | 382 years |
| Weight | 301.5 g |
| Display | Switching status: LED, yellow I1...I4; Power: LED, green AS-i; errors: LED, red |
| Housing | rectangular |
| Remarks | Do not connect any of the following points to an external potential:; I-, I+, I1, I2, I3, I4; The connections are electrically connected with the AS-i cable. |
| Material | PA; Socket: brass nickel-plated; O-ring: FKM |
| Connector | M12; coding: A; Contacts: 4 |
| Data bits | Data bit: D0: D1: D2: D3; Input: 1: 2: 3: 4; Socket: I-1: I-2: I-3: I-4; Pin: 2+4: 2+4: 2+4: 2+4 |
| Dimensions | 118.2 x 60 x 27 mm |
| Protection | IP 67; (when flat cables are used E7400x / E7401x) |
| Application | field installation |
| UL approval | voltage supply: Class 2 |
| AS-i ID code | 0.E hex |
| AS-i profile | S-0.0.E |
| AS-i version | 2.11; 3.0 |
| Pack quantity | 1 pcs. |
| Voltage supply | 20...30; (DC) V |
| AS-i addressing | IR addressing possible |
| AS-i certificate | 40501 |
| Type of mounting | Backplane mounting |
| Input current low | 0...2 mA |
| Module connection | M12 |
| Operating voltage | 26.5...31.6 DC V |
| Input current High | 6...10 mA |
| Ambient temperature | -25...80 °C |
| AS-i master profile | M2; M3; M4 |
| Storage temperature | -25...80 °C |
| Accessories (optional) | stainless steel sleeve, for installation in case of high mechanical stress , E70402 |
| Switching level high | > 11 V |
| AS-i I/O configuration | 0 hex |
| Extended addressing mode | no |
| Input current limitation | 15 mA |
| Number of digital inputs | 4 |
| Max. relative air humidity | 90; (non condensing) % |
| Max. height above sea level | 2000 m |
| Sensor supply of the inputs | AS-i |
| Number of inputs and outputs | Number of digital inputs: 4 |
| Input circuit of digital inputs | PNP; (type 2 according to IEC 61131-2) |
| Max. current consumption from AS-i | 250 mA |
| Max. total current rating of inputs | 200 mA |
| Digital inputs protected against short circuits | yes |
