IFM AC2413 AS-Interface CompactLine module
- Brand
- IFM
- Model
- AC2413
- GEARWELL SKU
- GWP-000029955
- Category
- PLCs & I/O
Key specifications
- EMC
- EN 61000-6-2; EN 62026-2; EN 50581
- Weight
- 272.5 g
- Housing
- rectangular
- Material
- PA 6.6; Socket: brass nickel-plated; threaded inserts in the lower part: brass nickel-plated; O-ring: FKM; Piercing contacts: CuSn6 nickel-plated and tin-plated
- Connector
- M12; coding: A; Contacts: 5
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM AC2413 AS-Interface CompactLine module |
|---|---|
| Brand | IFM |
| Model | AC2413 |
| Category | PLCs & I/O |
| EMC | EN 61000-6-2; EN 62026-2; EN 50581 |
| Weight | 272.5 g |
| Housing | rectangular |
| Material | PA 6.6; Socket: brass nickel-plated; threaded inserts in the lower part: brass nickel-plated; O-ring: FKM; Piercing contacts: CuSn6 nickel-plated and tin-plated |
| Connector | M12; coding: A; Contacts: 5 |
| Dimensions | 118.2 x 60 x 27 mm |
| Protection | IP 67; (when flat cables are used E7400x / E7401x) |
| Application | field installation |
| UL approval | voltage supply: Class 2 |
| Pack quantity | 1 pcs. |
| Type of mounting | AS-i flat cable connection; Backplane mounting |
| Module connection | Flat cable |
| Operating voltage | 26.5...31.6 DC V |
| Ambient temperature | -25...80 °C |
| Storage temperature | -25...80 °C |
| Accessories (optional) | stainless steel sleeve, for installation in case of high mechanical stress , E70402 |
| Max. current load total | 4 A |
| Additional voltage supply | 20...30 DC; (AUX) V |
| Max. relative air humidity | 90; (non condensing) % |
| Max. height above sea level | 2000 m |
| Max. current consumption from AS-i | 2000 mA |
| Max. current consumption from additional supply | 2000; (AUX) mA |
