IDEC SN2S-05D SN Series 2-Pole DIN Rail Relay Socket, Screw Terminal
- Brand
- IDEC
- Model
- SN2S-05D
- GEARWELL SKU
- GWP-000021652
- Category
- Contactors & Starters
Key specifications
- Rated current
- 10 A
- Terminal style
- M3 slotted Phillips screw
- Applicable wire
- 0.5 to 2.5 mm²
- Number of poles
- 2
- Hold-down spring
- SFA-502
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IDEC SN2S-05D SN Series 2-Pole DIN Rail Relay Socket, Screw Terminal |
|---|---|
| Brand | IDEC |
| Model | SN2S-05D |
| Category | Contactors & Starters |
| Rated current | 10 A |
| Terminal style | M3 slotted Phillips screw |
| Applicable wire | 0.5 to 2.5 mm² |
| Number of poles | 2 |
| Hold-down spring | SFA-502 |
| Applicable relays | RN2S, RU2S |
| Applicable standards | UL508, CSA C22.2 No.14, IEC61984 |
| Operating temperature | -40 to +70 °C |
| Rated insulation voltage | 300 V |
