IDEC RN2S-NL-D24 RN Series DPDT Miniature Power Relay 24V DC, LED
- Brand
- IDEC
- Model
- RN2S-NL-D24
- GEARWELL SKU
- GWP-000021642
- Category
- Contactors & Starters
Key specifications
- LED indicator
- With LED (NL)
- Coil resistance
- 640 Ω
- Electrical life
- 100,000 operations minimum
- Contact material
- Ag alloy
- Coil rated current
- 37.5 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IDEC RN2S-NL-D24 RN Series DPDT Miniature Power Relay 24V DC, LED |
|---|---|
| Brand | IDEC |
| Model | RN2S-NL-D24 |
| Category | Contactors & Starters |
| LED indicator | With LED (NL) |
| Coil resistance | 640 Ω |
| Electrical life | 100,000 operations minimum |
| Contact material | Ag alloy |
| Coil rated current | 37.5 mA |
| Coil rated voltage | 24 V DC |
| Contact configuration | DPDT (2 poles) |
| Operating temperature | -40 to +70 °C |
| Coil power consumption | approx. 0.9 W |
| Contact rating (resistive) | 5 A at 250 V AC / 5 A at 30 V DC |
| Applicable socket (DIN rail, screw) | SN2S-05D |
