HYDAC HDA 4845-A-100-000 HDA 4800 Pressure Transmitter 0-100 bar
- Brand
- HYDAC
- Model
- HDA 4845-A-100-000
- GEARWELL SKU
- GWP-000021670
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy
- 0.25 % max. / 0.125 % typ.
- Approval
- UL
- Part number
- 924204
- Output signal
- 4 to 20 mA (2 conductors)
- Pressure range
- 0 to 100 bar
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HYDAC HDA 4845-A-100-000 HDA 4800 Pressure Transmitter 0-100 bar |
|---|---|
| Brand | HYDAC |
| Model | HDA 4845-A-100-000 |
| Category | Pressure, Flow & Temperature |
| Accuracy | 0.25 % max. / 0.125 % typ. |
| Approval | UL |
| Part number | 924204 |
| Output signal | 4 to 20 mA (2 conductors) |
| Pressure range | 0 to 100 bar |
| Type of pressure | Relative |
| Electrical connection | DIN EN 175301-803, 3 pin + PE |
| Mechanical connection | G1/4 A ISO 1179-2, external |
