HONEYWELL WS8B2WB/U WS8 Series Fan Coil Thermostat

Key specifications

Backlight: White
Control mode: On/off output
Fan coil type: 2-pipe
Load capacity: Fan: resistive 3 A, inductive 1 A; valve: resistive 2 A, inductive 0.6 A
Supply voltage: 100 to 240 VAC, 50/60 Hz

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	HONEYWELL WS8B2WB/U WS8 Series Fan Coil Thermostat
Brand	HONEYWELL
Model	WS8B2WB/U
Category	Pressure, Flow & Temperature
Backlight	White
Control mode	On/off output
Fan coil type	2-pipe
Load capacity	Fan: resistive 3 A, inductive 1 A; valve: resistive 2 A, inductive 0.6 A
Supply voltage	100 to 240 VAC, 50/60 Hz
Protection class	IP20
Ventilation mode	Yes
Temperature setting range	10 to 30 °C
