HONEYWELL WL8B4WB WL8 Series Digital Fan Coil Thermostat
- Brand
- HONEYWELL
- Model
- WL8B4WB
- GEARWELL SKU
- GWP-000022433
- Category
- Pressure, Flow & Temperature
Key specifications
- Control mode
- On/off output
- Fan coil type
- 2-pipe / 4-pipe
- Load capacity
- Fan/valve: resistive 2 A, inductive 0.6 A
- Supply voltage
- 220 VAC, 50 Hz
- Control accuracy
- +/-1 °C at 21 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HONEYWELL WL8B4WB WL8 Series Digital Fan Coil Thermostat |
|---|---|
| Brand | HONEYWELL |
| Model | WL8B4WB |
| Category | Pressure, Flow & Temperature |
| Control mode | On/off output |
| Fan coil type | 2-pipe / 4-pipe |
| Load capacity | Fan/valve: resistive 2 A, inductive 0.6 A |
| Supply voltage | 220 VAC, 50 Hz |
| Control accuracy | +/-1 °C at 21 °C |
| Protection class | IP20 |
| Energy-saving mode | No |
| Temperature setting range | 10 to 32 °C |
| External temperature sensor | Not supported |
