GIC HM107B-0000 7-inch TFT HMI Touch Panel
- Brand
- GIC
- Model
- HM107B-0000
- GEARWELL SKU
- GWP-000024387
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- Cortex-M7, 600 MHz
- USB
- 1 x host, 1 x slave
- Memory
- 32 MB RAM / 32 MB ROM (non-Ethernet model)
- Display
- 7" TFT, 800 x 480
- Ethernet
- none (HM107B-N000 is the Ethernet version)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GIC HM107B-0000 7-inch TFT HMI Touch Panel |
|---|---|
| Brand | GIC |
| Model | HM107B-0000 |
| Category | HMIs & Industrial PCs |
| CPU | Cortex-M7, 600 MHz |
| USB | 1 x host, 1 x slave |
| Memory | 32 MB RAM / 32 MB ROM (non-Ethernet model) |
| Display | 7" TFT, 800 x 480 |
| Ethernet | none (HM107B-N000 is the Ethernet version) |
| Protection | IP65 front panel; PCB conformal coating |
| Touch panel | Resistive |
| Power supply | 24 V DC |
| Serial ports | 1 x RS232/RS485, 1 x RS232/RS422/RS485 |
| Operating temperature | 0 to 50 °C |
