GEFRAN F056919 K72-8-M-B07C-1-3-D-I-P-E Melt Pressure Transmitter
- Brand
- GEFRAN
- Model
- F056919
- GEARWELL SKU
- GWP-000021369
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- K7 Series - NaK-filled melt pressure transmitter, voltage output (PLc / SIL2 versions)
- Option code
- 2130B000S00
- Part number
- F056919
- Type designation
- K72-8-M-B07C-1-3-D-I-P-E
- Gefran product ID
- F056919
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GEFRAN F056919 K72-8-M-B07C-1-3-D-I-P-E Melt Pressure Transmitter |
|---|---|
| Brand | GEFRAN |
| Model | F056919 |
| Category | Pressure, Flow & Temperature |
| Series | K7 Series - NaK-filled melt pressure transmitter, voltage output (PLc / SIL2 versions) |
| Option code | 2130B000S00 |
| Part number | F056919 |
| Type designation | K72-8-M-B07C-1-3-D-I-P-E |
| Gefran product ID | F056919 |
| Accuracy class (code "M") | < ±0.5% FS |
| Process thread (code "1") | 1/2-20UNF |
| Series pressure ranges | 0-35 to 0-1000 bar / 0-500 to 0-15000 psi |
| Pressure range (code "B07C") | 0-700 bar |
| Flexible stem length (code "D") | 457 mm (18 in) |
