GEFRAN F036770 IN1-M-6-M-B07C-1-4-D Melt Pressure Transmitter
- Brand
- GEFRAN
- Model
- F036770
- GEARWELL SKU
- GWP-000014011
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- IN
- Version
- Rigid stem + flexible sheath
- Code suffix "M"
- as collected; not listed in the official model-number table
- Accuracy class
- <±0.5% FSO (M)
- Process thread
- 1/2-20 UNF
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GEFRAN F036770 IN1-M-6-M-B07C-1-4-D Melt Pressure Transmitter |
|---|---|
| Brand | GEFRAN |
| Model | F036770 |
| Category | Pressure, Flow & Temperature |
| Series | IN |
| Version | Rigid stem + flexible sheath |
| Code suffix "M" | as collected; not listed in the official model-number table |
| Accuracy class | <±0.5% FSO (M) |
| Process thread | 1/2-20 UNF |
| Type designation | IN1-M-6-M-B07C-1-4-D 2130X000X00 |
| Measurement range | 0-700 bar |
| Electrical connection | 6-pin connector VPT07RA10-6PT2 |
| Stem / flexible length codes | 4 / D (as in the official type designation) |
| Product ID (Gefran order number) | F036770 |
