GE URRHH Multilin UR RH High-Range Power Supply Module
- Brand
- GE
- Model
- URRHH
- GEARWELL SKU
- GWP-000026396
- Category
- Power Supplies
Key specifications
- Evidence
- GE Vernova product notification GET-20112 (UR-RH 2nd-generation HI power supply) + C30 manual order code RH; module data from AX Control
- Order code
- UR-RHH (power supply option RH, mounting letter H)
- Rated power
- 35 W at 125-250 V DC; 35 VA at 100-240 V AC
- Internal fuse
- 4 A / 250 V
- Voltage range
- 125/250 V AC/DC (HI range)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE URRHH Multilin UR RH High-Range Power Supply Module |
|---|---|
| Brand | GE |
| Model | URRHH |
| Category | Power Supplies |
| Evidence | GE Vernova product notification GET-20112 (UR-RH 2nd-generation HI power supply) + C30 manual order code RH; module data from AX Control |
| Order code | UR-RHH (power supply option RH, mounting letter H) |
| Rated power | 35 W at 125-250 V DC; 35 VA at 100-240 V AC |
| Internal fuse | 4 A / 250 V |
| Voltage range | 125/250 V AC/DC (HI range) |
| Weight (approx.) | 2 lb 2 oz |
| Dimensions (approx.) | 6.5 in L x 6.5 in W x 1.75 in H |
| Module generation | 2nd generation UR-RH high-voltage power supply (succeeded by SH in 2014, TH in 2023) |
| Unit mounting letter | H (horizontal-mount UR chassis) |
