GE SFLA36AI0250 Spectra RMS SF250 Mag-Break Circuit Breaker
- Brand
- GE
- Model
- SFLA36AI0250
- GEARWELL SKU
- GWP-000014716
- Category
- Circuit Protection
Key specifications
- UPC
- 783164211610
- Lugs
- TCAL29
- Poles
- 3
- Approvals
- UL File E11592; CSA LR40350
- Frame type
- SF250
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE SFLA36AI0250 Spectra RMS SF250 Mag-Break Circuit Breaker |
|---|---|
| Brand | GE |
| Model | SFLA36AI0250 |
| Category | Circuit Protection |
| UPC | 783164211610 |
| Lugs | TCAL29 |
| Poles | 3 |
| Approvals | UL File E11592; CSA LR40350 |
| Frame type | SF250 |
| Description | F-FRAME 3P 600V 250A MAG-BREAK |
| Trip function | Mag only, adjustable instantaneous |
| Interrupting rating | 100 kAIC @240 Vac; 65 kAIC @480 Vac; 25 kAIC @600 Vac |
| Amperage (rating plug) | 70 to 250 A |
