GE SKLA36AT1200 Spectra RMS SK1200 Molded Case Circuit Breaker
- Brand
- GE
- Model
- SKLA36AT1200
- GEARWELL SKU
- GWP-000026260
- Category
- Circuit Protection
Key specifications
- Frame
- SK1200 (K = 1200 A frame)
- Poles
- 3
- Evidence
- GE BuyLog Catalog section 6, Rev. 11/13 (hosted at assets.usesi.com)
- Rating plugs
- SRPK1200A600 to SRPK1200A1200 (600-1200 A)
- Terminal lugs
- TCAL125, (4) 250-500 kcmil Cu/Al
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE SKLA36AT1200 Spectra RMS SK1200 Molded Case Circuit Breaker |
|---|---|
| Brand | GE |
| Model | SKLA36AT1200 |
| Category | Circuit Protection |
| Frame | SK1200 (K = 1200 A frame) |
| Poles | 3 |
| Evidence | GE BuyLog Catalog section 6, Rev. 11/13 (hosted at assets.usesi.com) |
| Rating plugs | SRPK1200A600 to SRPK1200A1200 (600-1200 A) |
| Terminal lugs | TCAL125, (4) 250-500 kcmil Cu/Al |
| Voltage rating | 600 Vac max (UL/CSA); IEC 947-2 690 Vac max |
| Interrupting rating (L) | 65 kA @480 Vac |
| Trip unit / function (A, T) | Spectra RMS, LSI |
| Continuous load rating (A) | Standard |
