GE MIVII3000E00HI00 Multilin MIV II Voltage/Frequency Relay
- Brand
- GE
- Model
- MIVII3000E00HI00
- GEARWELL SKU
- GWP-000026258
- Category
- Circuit Protection
Key specifications
- Housing
- Stainless-steel 304, 1/4 of 19 in rack, 4 units high
- Language (E)
- English
- Functions (3)
- Voltage & frequency functions (MIV II 3000)
- Power supply (HI)
- 110-250 Vdc (88-300 Vdc), 110-230 Vac (88-264 Vac)
- Voltage range (0)
- 10-250 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE MIVII3000E00HI00 Multilin MIV II Voltage/Frequency Relay |
|---|---|
| Brand | GE |
| Model | MIVII3000E00HI00 |
| Category | Circuit Protection |
| Housing | Stainless-steel 304, 1/4 of 19 in rack, 4 units high |
| Language (E) | English |
| Functions (3) | Voltage & frequency functions (MIV II 3000) |
| Power supply (HI) | 110-250 Vdc (88-300 Vdc), 110-230 Vac (88-264 Vac) |
| Voltage range (0) | 10-250 V |
| Time delay range | 0 to 600 s |
| Voltage unbalance | Negative-sequence voltage unit included in MIV II 3000 |
| Conformal coating (0) | Without conformal coating |
| AC voltage input (high range) | 50-240 Vac, 50/60 Hz |
