GE IC755CSS15CDA-AC QuickPanel+ 15 in. View & Control Operator Panel
- Brand
- GE
- Model
- IC755CSS15CDA-AC
- GEARWELL SKU
- GWP-000025893
- Category
- HMIs & Industrial PCs
Key specifications
- Power
- 12/24 VDC +/-20%, max 30 W
- Memory
- 1 GB DDR3 SDRAM, 512 MB SLC NAND flash, 512 KB battery-backed SRAM
- Serial
- 1x RS-232, 1x RS-485
- Display
- 15 in. TFT LCD, 1024 x 768, projected capacitive multi-touch
- Ethernet
- 2x 10/100BaseT RJ-45
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC755CSS15CDA-AC QuickPanel+ 15 in. View & Control Operator Panel |
|---|---|
| Brand | GE |
| Model | IC755CSS15CDA-AC |
| Category | HMIs & Industrial PCs |
| Power | 12/24 VDC +/-20%, max 30 W |
| Memory | 1 GB DDR3 SDRAM, 512 MB SLC NAND flash, 512 KB battery-backed SRAM |
| Serial | 1x RS-232, 1x RS-485 |
| Display | 15 in. TFT LCD, 1024 x 768, projected capacitive multi-touch |
| Ethernet | 2x 10/100BaseT RJ-45 |
| Evidence | GE GFA2026C 15" QuickPanel+ data sheet (hosted at rexel-cdn.com) |
| Processor | Freescale i.MX535 1 GHz ARM Cortex A8 |
| Dimensions | 399 x 323 x 70 (W x H x D) mm |
| Panel cutout | 379 x 305 mm |
| Code suffix "-AC" | as collected; GE hardware/firmware revision suffix (catalog numbers are listed without it in GE documents); not listed in the official model-number table |
