GE IC660BBD101 Genius 115VAC 8-Circuit Low-Leakage I/O Block
- Brand
- GE
- Model
- IC660BBD101
- GEARWELL SKU
- GWP-000034256
- Category
- PLCs & I/O
Key specifications
- Weight
- 1.8 kg
- Circuits
- 8, each input or output
- Evidence
- GE Fanuc GFK-0035D 115VAC 8-Circuit Discrete I/O Block datasheet (hosted at qualitrol.com)
- Catalog number
- IC66*BBD101 (electronics IC66*EBD101, terminal IC66*TSD100)
- Size (H x W x D)
- 22.44 x 8.48 x 9.93 cm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC660BBD101 Genius 115VAC 8-Circuit Low-Leakage I/O Block |
|---|---|
| Brand | GE |
| Model | IC660BBD101 |
| Category | PLCs & I/O |
| Weight | 1.8 kg |
| Circuits | 8, each input or output |
| Evidence | GE Fanuc GFK-0035D 115VAC 8-Circuit Discrete I/O Block datasheet (hosted at qualitrol.com) |
| Catalog number | IC66*BBD101 (electronics IC66*EBD101, terminal IC66*TSD100) |
| Size (H x W x D) | 22.44 x 8.48 x 9.93 cm |
| Operating voltage | 93-132 VAC, 47-63 Hz |
| Input filter times | 10 to 100 ms in 10 ms steps |
| Operating temperature | 0 to +60 °C |
| Output current per circuit | 2 A RMS (steady state) |
| Maximum block output current | 15 A at 35 °C, 7.5 A at 60 °C |
