GE IC200MDL740 VersaMax 16-Point 12/24VDC Positive Logic Output Module
- Brand
- GE
- Model
- IC200MDL740
- GEARWELL SKU
- GWP-000025104
- Category
- PLCs & I/O
Key specifications
- Points
- 1 group of 16 outputs (positive logic / sourcing)
- Evidence
- GE GFK-2537 (hosted at qualitrol.com)
- Isolation
- User input to logic and frame ground: 250 VAC continuous, 1500 VAC for 1 min; point to point: none
- Protection
- No internal fuses
- Load current
- 0.5 A at 30 VDC max (resistive); 2.0 A max for 100 ms inrush
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC200MDL740 VersaMax 16-Point 12/24VDC Positive Logic Output Module |
|---|---|
| Brand | GE |
| Model | IC200MDL740 |
| Category | PLCs & I/O |
| Points | 1 group of 16 outputs (positive logic / sourcing) |
| Evidence | GE GFK-2537 (hosted at qualitrol.com) |
| Isolation | User input to logic and frame ground: 250 VAC continuous, 1500 VAC for 1 min; point to point: none |
| Protection | No internal fuses |
| Load current | 0.5 A at 30 VDC max (resistive); 2.0 A max for 100 ms inrush |
| Response time | On 0.2 ms max / Off 1.0 ms max |
| Output voltage | +10.2 to +30 (12/24 nominal) VDC |
| Output voltage drop | 0.3 max V |
| Output leakage current | 0.5 mA at 30 VDC max |
| Backplane current consumption | 45 mA max (5 V) |
