GE IC200ALG240 VersaMax Isolated Analog Input Module
- Brand
- GE
- Model
- IC200ALG240
- GEARWELL SKU
- GWP-000034248
- Category
- PLCs & I/O
Key specifications
- Channels
- 8 isolated inputs
- Evidence
- GE Fanuc GFK-1522A Analog Input Module, 16-Bit, 8 Isolated Inputs datasheet (hosted at qualitrol.com)
- Resolution
- 16-bit
- Accuracy at 25 °C
- +/-0.1% max of full scale
- Backplane current
- 15 mA at 5 V; 120 mA at 3.3 V (max)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC200ALG240 VersaMax Isolated Analog Input Module |
|---|---|
| Brand | GE |
| Model | IC200ALG240 |
| Category | PLCs & I/O |
| Channels | 8 isolated inputs |
| Evidence | GE Fanuc GFK-1522A Analog Input Module, 16-Bit, 8 Isolated Inputs datasheet (hosted at qualitrol.com) |
| Resolution | 16-bit |
| Accuracy at 25 °C | +/-0.1% max of full scale |
| Backplane current | 15 mA at 5 V; 120 mA at 3.3 V (max) |
| External power supply | +19.5 to +30 VDC, 100 mA max plus load currents |
| Input operating range | Current 1-20 mA; voltage +/-10 VDC |
| Channel data update rate | approx. 20 ms max @ 50 Hz filter, 16.7 ms @ 60 Hz |
| Channel-to-channel isolation | 250 VAC continuous; 1500 VAC for 1 minute |
