GE H201TI Hydran 201Ti Transformer DGA Monitor
- Brand
- GE
- Model
- H201TI
- GEARWELL SKU
- GWP-000025645
- Category
- Test & Measurement
Key specifications
- Power
- 90-132 Vac or 180-264 Vac switchable, 47-63 Hz, 475 VA max
- Display
- Backlit LCD, 2 lines x 16 characters
- Accuracy
- ±10% of reading ±25 ppm (H2 equivalent)
- Enclosure
- NEMA Type 4X, meets IP56
- Communication
- USB (type B), isolated RS-485 Modbus
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE H201TI Hydran 201Ti Transformer DGA Monitor |
|---|---|
| Brand | GE |
| Model | H201TI |
| Category | Test & Measurement |
| Power | 90-132 Vac or 180-264 Vac switchable, 47-63 Hz, 475 VA max |
| Display | Backlit LCD, 2 lines x 16 characters |
| Accuracy | ±10% of reading ±25 ppm (H2 equivalent) |
| Enclosure | NEMA Type 4X, meets IP56 |
| Communication | USB (type B), isolated RS-485 Modbus |
| Response time | 10 minutes (90% of step change) |
| Sensor options | Composite Gas (H2, CO, C2H2, C2H4) / Hydrogen Only (specify on order) |
| Measuring range | 25-2000 ppm (v/v, H2 equivalent) |
| Dimensions / weight | dia. 178 mm x 180 mm; 5.6 kg installed |
| Operating ambient temperature | -40 to +55 °C |
