GE DS200SDCIG2AHB DS200 Power Supply and Instrumentation Board
- Brand
- GE
- Model
- DS200SDCIG2AHB
- GEARWELL SKU
- GWP-000025294
- Category
- Variable Frequency Drives
Key specifications
- Fuses
- FU1-FU3, FU5, FU6
- Manual
- GEI-100173
- Weight
- 1 lb
- Evidence
- AX Control (no current official GE page or archived GE PDF found)
- Application
- interface to DC2000 model drives
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE DS200SDCIG2AHB DS200 Power Supply and Instrumentation Board |
|---|---|
| Brand | GE |
| Model | DS200SDCIG2AHB |
| Category | Variable Frequency Drives |
| Fuses | FU1-FU3, FU5, FU6 |
| Manual | GEI-100173 |
| Weight | 1 lb |
| Evidence | AX Control (no current official GE page or archived GE PDF found) |
| Application | interface to DC2000 model drives |
| Product type | Power Supply and Instrumentation Board |
| Jumpers / switch | JP1 MD control source; JP2 MA AC contactor drop-out time; SW1 CT line burden select |
| Power circuits | +5 VDC 4 A; +/-15 VDC 0.4 A; +/-24 VDC; 115 VAC 0.4 A |
