GE 750-P5-G5-S5-HI-A20-R Multilin 750 Feeder Protection Relay
- Brand
- GE
- Model
- 750-P5-G5-S5-HI-A20-R
- GEARWELL SKU
- GWP-000026209
- Category
- Machine Safety & Vision
Key specifications
- Evidence
- GE Vernova Multilin 750/760 brochure GEA-31955 (ordering table)
- Order code
- 750-P5-G5-S5-HI-A20-R (collected with 'SR' prefix)
- Seller code
- SR750-P5-G5-S5-HI-A20-R (GE names the product SR750; official order code is written 750-...)
- Control power (HI)
- 88-300 V DC; 70-265 V AC at 48-62 Hz
- Analog outputs (A20)
- Eight 4-20 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE 750-P5-G5-S5-HI-A20-R Multilin 750 Feeder Protection Relay |
|---|---|
| Brand | GE |
| Model | 750-P5-G5-S5-HI-A20-R |
| Category | Machine Safety & Vision |
| Evidence | GE Vernova Multilin 750/760 brochure GEA-31955 (ordering table) |
| Order code | 750-P5-G5-S5-HI-A20-R (collected with 'SR' prefix) |
| Seller code | SR750-P5-G5-S5-HI-A20-R (GE names the product SR750; official order code is written 750-...) |
| Control power (HI) | 88-300 V DC; 70-265 V AC at 48-62 Hz |
| Analog outputs (A20) | Eight 4-20 mA |
| Breaker status LED (R) | Red breaker closed LED |
| Operating temperature | -40 to +60 °C |
| Phase current inputs (P5) | 5 A |
| Ground current inputs (G5) | 5 A zero sequence |
| Sensitive ground current input (S5) | 5 A |
