Fuji Electric SC-N12/VS48-C Mechanical Latch Magnetic Contactor
- Brand
- Fuji Electric
- Model
- SC-N12/VS48-C
- GEARWELL SKU
- GWP-000021771
- Category
- Contactors & Starters
Key specifications
- Coil
- SUPER MAGNET, operates on AC or DC
- Type
- SC-N12/VS mechanical latch contactor, non-reversing
- Code suffix "48-C"
- as collected; not listed in the official model-number table
- Ordering code (catalogue)
- SC4ABAE-□12 (□ = coil voltage code)
- Rated thermal current Ith
- 450 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Fuji Electric SC-N12/VS48-C Mechanical Latch Magnetic Contactor |
|---|---|
| Brand | Fuji Electric |
| Model | SC-N12/VS48-C |
| Category | Contactors & Starters |
| Coil | SUPER MAGNET, operates on AC or DC |
| Type | SC-N12/VS mechanical latch contactor, non-reversing |
| Code suffix "48-C" | as collected; not listed in the official model-number table |
| Ordering code (catalogue) | SC4ABAE-□12 (□ = coil voltage code) |
| Rated thermal current Ith | 450 A |
| Max. motor capacity 200-240 V | 120 kW |
| Max. motor capacity 380-440 V | 220 kW |
| Rated operational current 380-440 V | 400 A |
| Coil power consumption (AC) closing / tripping | 490 / 385 W |
