FOTEK SM-30 SM Series Tachometer & Line Speed Meter
- Brand
- FOTEK
- Model
- SM-30
- GEARWELL SKU
- GWP-000021107
- Category
- Test & Measurement
Key specifications
- Digits
- 4
- Outline
- 72x72x128 (panel cut-out 68x68) mm
- DC output
- 12 V / 100 mA max.
- Alarm output
- relay
- Input method
- NPN
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK SM-30 SM Series Tachometer & Line Speed Meter |
|---|---|
| Brand | FOTEK |
| Model | SM-30 |
| Category | Test & Measurement |
| Digits | 4 |
| Outline | 72x72x128 (panel cut-out 68x68) mm |
| DC output | 12 V / 100 mA max. |
| Alarm output | relay |
| Input method | NPN |
| Power supply | 90~265 VAC 50/60 Hz |
| Output control | Hi / Lo |
| Operating ambient | -20~80 °C; 35~85% RH |
| Pulses per revolution | 1~999 PPR settable |
