FOTEK H3-M1-24VDC H3 Series Multi-Range Power-On Delay Timer
- Brand
- FOTEK
- Model
- H3-M1-24VDC
- GEARWELL SKU
- GWP-000021018
- Category
- PLCs & I/O
Key specifications
- Ambient
- -20~60 °C; 35~85% RH
- Dimension
- 40x50 mm
- Reset time
- 0.1 s max.
- Time ranges
- 1S/10S/1M/10M
- Control output
- relay, 10 A contact rating
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK H3-M1-24VDC H3 Series Multi-Range Power-On Delay Timer |
|---|---|
| Brand | FOTEK |
| Model | H3-M1-24VDC |
| Category | PLCs & I/O |
| Ambient | -20~60 °C; 35~85% RH |
| Dimension | 40x50 mm |
| Reset time | 0.1 s max. |
| Time ranges | 1S/10S/1M/10M |
| Control output | relay, 10 A contact rating |
| Repeat accuracy | 0.2% of F.S. max. |
| Setting accuracy | 5% of F.S. max. |
| Supply voltage (as collected) | 24 VDC |
| Supply voltage options (official) | 12 or 24 VAC/DC; 110, 230 or 380 VAC 50/60 Hz |
