FOTEK DRM-141-mV Digital Meter Preset Digital Scale Panel Meter
- Brand
- FOTEK
- Model
- DRM-141-mV
- GEARWELL SKU
- GWP-000020996
- Category
- Test & Measurement
Key specifications
- Memory
- EEPROM
- Outline
- DIN 48 x 24 mm
- Accuracy
- ±0.1% of F.S.
- Alarm modes
- ALt.0 ~ ALt.3 (high / low / band alarm with hysteresis)
- Input range
- 0~100 mVDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK DRM-141-mV Digital Meter Preset Digital Scale Panel Meter |
|---|---|
| Brand | FOTEK |
| Model | DRM-141-mV |
| Category | Test & Measurement |
| Memory | EEPROM |
| Outline | DIN 48 x 24 mm |
| Accuracy | ±0.1% of F.S. |
| Alarm modes | ALt.0 ~ ALt.3 (high / low / band alarm with hysteresis) |
| Input range | 0~100 mVDC |
| Panel cutout | 44.5 x 22.5 mm |
| Power supply | 90~250 VAC 50/60 Hz, or 24 VDC/AC or 48 VDC/AC |
| Display range | -1999~9999 (4 digits) |
| Response time | 200 ms |
| Control output | Relay 5 A / 250 VAC |
