FOTEK DPM-2 DPM Series Dew Point/Humidity/Temperature Meter
- Brand
- FOTEK
- Model
- DPM-2
- GEARWELL SKU
- GWP-000022716
- Category
- Pressure, Flow & Temperature
Key specifications
- Range
- RH 0.0-99.9 %, dew point -69 to 20.0 °C, temperature 0-999 °C
- Outline
- 96 x 48 mm
- Outputs
- Temp relay 1c, DP/RH relay 1a (5 A/250 V AC)
- Sensor 1
- K, J or PT
- Sensor 2
- RH sensor 0.800-3.800 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK DPM-2 DPM Series Dew Point/Humidity/Temperature Meter |
|---|---|
| Brand | FOTEK |
| Model | DPM-2 |
| Category | Pressure, Flow & Temperature |
| Range | RH 0.0-99.9 %, dew point -69 to 20.0 °C, temperature 0-999 °C |
| Outline | 96 x 48 mm |
| Outputs | Temp relay 1c, DP/RH relay 1a (5 A/250 V AC) |
| Sensor 1 | K, J or PT |
| Sensor 2 | RH sensor 0.800-3.800 V DC |
| Power supply | 90-265 V AC, 50/60 Hz, 5 VA max. |
| Control method | ON/OFF |
| Display accuracy | ±(0.1 % F.S. + 1 digit) |
| DP/RH transmitter | None |
