FOTEK DA-24T-2 AV/AA/DV/DA Series DC Digital Panel Ammeter
- Brand
- FOTEK
- Model
- DA-24T-2
- GEARWELL SKU
- GWP-000020991
- Category
- Test & Measurement
Key specifications
- Display
- 4 digits, 0~9999
- Outline
- DIN 96 x 48 mm
- Accuracy
- ±0.1% of F.S. + 1 digit
- Base type
- DA-24T (DC Current Meter, input 0~10 A DC)
- Input range
- 0~10 A DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK DA-24T-2 AV/AA/DV/DA Series DC Digital Panel Ammeter |
|---|---|
| Brand | FOTEK |
| Model | DA-24T-2 |
| Category | Test & Measurement |
| Display | 4 digits, 0~9999 |
| Outline | DIN 96 x 48 mm |
| Accuracy | ±0.1% of F.S. + 1 digit |
| Base type | DA-24T (DC Current Meter, input 0~10 A DC) |
| Input range | 0~10 A DC |
| Panel cutout | 92.0 x 45.0 mm |
| Power supply | 90~265 VAC 50/60 Hz (standard); 10~60 VAC/DC with 24V power option |
| Code suffix "-2" | as collected; not listed in the official model-number table (official key example DA-24T-mV-24V = type-outline-input-power supply) |
| Power supply options | standard 90~265 VAC / 24V = 10~60 VAC/DC (specify on order) |
