Flexem FE7100WE-UL 7000 Series 10.1-inch IoT HMI with Ethernet
- Brand
- Flexem
- Model
- FE7100WE-UL
- GEARWELL SKU
- GWP-000024324
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- 1 GHz quad-core Cortex-A7
- Display
- 10.1" 16:9 TFT LCD, 24-bit
- Ethernet
- 1x RJ45 10/100 Mbps
- Dimensions
- 273 x 213 x 36 mm
- Resolution
- 1024 x 600
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Flexem FE7100WE-UL 7000 Series 10.1-inch IoT HMI with Ethernet |
|---|---|
| Brand | Flexem |
| Model | FE7100WE-UL |
| Category | HMIs & Industrial PCs |
| CPU | 1 GHz quad-core Cortex-A7 |
| Display | 10.1" 16:9 TFT LCD, 24-bit |
| Ethernet | 1x RJ45 10/100 Mbps |
| Dimensions | 273 x 213 x 36 mm |
| Resolution | 1024 x 600 |
| Touch panel | 4-wire resistive |
| Panel cutout | 260 x 202 mm |
| Serial ports | COM1 RS232/RS485/RS422, COM2 RS485, COM3 RS232 |
| Rated voltage | DC24V (9-28 V), <10 W |
