EUCHNER 910-AP-156652 Safety Light Curtain
- Brand
- EUCHNER
- Model
- 910-AP-156652
- GEARWELL SKU
- GWP-000000988
- Category
- Industrial Automation Parts
Key specifications
- Connection
- M12; transmitter 5-pin and receiver 8-pin
- Resolution
- 40 mm
- Product type
- Safety light curtain
- Response time
- 9.5 ms
- Operating range
- 12 m
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The EUCHNER LCA-2TR-40-910-AP-156652 is an EUCHNER LCA safety light curtain for hand protection, order no. 156652, with a resolution of 40 mm, a protective field height of 910 mm and a range of 12 m. It is an ESPE of type 2 according to EN 61496-1 and reaches PL c, category 2 and SIL 1, with a response time of 9.5 ms. The receiver has 2 static, self-monitoring PNP safety outputs rated up to 400 mA each, and transmitter and receiver connect through M12 plug connectors (5-pin and 8-pin) on 24 V DC. Protection is IP65/IP67 for -30 to 55 °C, and installation material is included.
Technical reference
| Product name | EUCHNER 910-AP-156652 Safety Light Curtain |
|---|---|
| Brand | EUCHNER |
| Model | 910-AP-156652 |
| Category | Industrial Automation Parts |
| Connection | M12; transmitter 5-pin and receiver 8-pin |
| Resolution | 40 mm |
| Product type | Safety light curtain |
| Response time | 9.5 ms |
| Operating range | 12 m |
| Operating voltage | 24 V DC (-20% / +20%) |
| Protection rating | IP65 / IP67 |
| Protective field height | 910 mm |
