Endress+Hauser TMR35-A1XBDBAX1AAA Easytemp Hygienic Thermometer
- Brand
- Endress+Hauser
- Model
- TMR35-A1XBDBAX1AAA
- GEARWELL SKU
- GWP-000022570
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- Pt100 4-wire or PC-programmable 4 to 20 mA transmitter (per order code)
- Sensor
- Pt100 thin-film, accuracy class A (IEC 60751)
- Code positions
- as collected; individual order-code positions are not tabulated in the opened Technical Information (selected when ordering)
- Hygienic design
- 3-A marking, EHEDG certification (TMR35)
- Measuring range
- -50 to 150 (up to 200 with extension neck) °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Endress+Hauser TMR35-A1XBDBAX1AAA Easytemp Hygienic Thermometer |
|---|---|
| Brand | Endress+Hauser |
| Model | TMR35-A1XBDBAX1AAA |
| Category | Pressure, Flow & Temperature |
| Output | Pt100 4-wire or PC-programmable 4 to 20 mA transmitter (per order code) |
| Sensor | Pt100 thin-film, accuracy class A (IEC 60751) |
| Code positions | as collected; individual order-code positions are not tabulated in the opened Technical Information (selected when ordering) |
| Hygienic design | 3-A marking, EHEDG certification (TMR35) |
| Measuring range | -50 to 150 (up to 200 with extension neck) °C |
| Electrical connection | M12 connector, IP69K |
| Technical Information | TI00123R/14/FR/18.18 |
| Insertion length range | 40 to 600 mm |
| Order code (as collected) | TMR35-A1XBDBAX1AAA |
