Endress+Hauser TMR31-A11ABBAB1AAA TMR31 Compact Pt100 Thermometer
- Brand
- Endress+Hauser
- Model
- TMR31-A11ABBAB1AAA
- GEARWELL SKU
- GWP-000022552
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 4-20 mA (PC-programmable) or Pt100 4-wire
- Series
- Compact thermometer TMR31
- Response time
- t50 = 1 s, t90 = 2 s
- Probe diameter
- 4 or 6 mm
- Probe material
- 1.4404 (316L)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Endress+Hauser TMR31-A11ABBAB1AAA TMR31 Compact Pt100 Thermometer |
|---|---|
| Brand | Endress+Hauser |
| Model | TMR31-A11ABBAB1AAA |
| Category | Pressure, Flow & Temperature |
| Output | 4-20 mA (PC-programmable) or Pt100 4-wire |
| Series | Compact thermometer TMR31 |
| Response time | t50 = 1 s, t90 = 2 s |
| Probe diameter | 4 or 6 mm |
| Probe material | 1.4404 (316L) |
| Operating range | -50 to 200 °C |
| Process connection | G1/4", G1/2", NPT1/4", NPT1/2", M14x1.5, M18x1.5, R1/2" |
| Measuring principle | RTD Pt100, class A per IEC 60751 |
| Max. process pressure | 100 bar at 20 °C |
| Order code (as collected) | TMR31-A11ABBAB1AAA |
| Code suffix "-A11ABBAB1AAA" | as collected; not listed in an opened official model-number table |
