Endress+Hauser COS61D-AAA1A3 Oxymax COS61D Optical Oxygen Sensor
- Brand
- Endress+Hauser
- Model
- COS61D-AAA1A3
- GEARWELL SKU
- GWP-000022462
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- Oxymax COS61D
- Materials
- Shaft stainless steel 1.4571, membrane cap POM
- Dimensions
- Ø40 mm, shaft length 186 mm
- Measuring range
- 0 to 20 mg/l; 0 to 200 %SAT; 0 to 400 hPa
- Process pressure
- max. 10 bar abs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Endress+Hauser COS61D-AAA1A3 Oxymax COS61D Optical Oxygen Sensor |
|---|---|
| Brand | Endress+Hauser |
| Model | COS61D-AAA1A3 |
| Category | Pressure, Flow & Temperature |
| Series | Oxymax COS61D |
| Materials | Shaft stainless steel 1.4571, membrane cap POM |
| Dimensions | Ø40 mm, shaft length 186 mm |
| Measuring range | 0 to 20 mg/l; 0 to 200 %SAT; 0 to 400 hPa |
| Process pressure | max. 10 bar abs |
| Code suffix "-AAA1A3" | as collected; not listed in an opened official model-number table |
| Process connection | G1 or NPT 3/4" |
| Measuring principle | Optical (fluorescence quenching), Memosens |
| Process temperature | -5 to 60 °C |
| Order code (as collected) | COS61D-AAA1A3 |
