Endress+Hauser CLS50-A1B2 Indumax CLS50 Inductive Conductivity Sensor
- Brand
- Endress+Hauser
- Model
- CLS50-A1B2
- GEARWELL SKU
- GWP-000022460
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- Indumax CLS50
- Measuring range
- 2 µS/cm to 2000 mS/cm
- Code suffix "-A1B2"
- as collected; not listed in an opened official model-number table
- Process pressure
- max. 20 bar (PEEK) / 16 bar (PFA)
- Ingress protection
- IP67
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Endress+Hauser CLS50-A1B2 Indumax CLS50 Inductive Conductivity Sensor |
|---|---|
| Brand | Endress+Hauser |
| Model | CLS50-A1B2 |
| Category | Pressure, Flow & Temperature |
| Series | Indumax CLS50 |
| Measuring range | 2 µS/cm to 2000 mS/cm |
| Code suffix "-A1B2" | as collected; not listed in an opened official model-number table |
| Process pressure | max. 20 bar (PEEK) / 16 bar (PFA) |
| Ingress protection | IP67 |
| Process connection | NPT 1", DN50, ANSI or JIS |
| Temperature sensor | Pt100 integrated |
| Measuring principle | Inductive (toroidal), analog |
| Process temperature | max. 180 (PEEK) / 125 (PFA) °C |
| Order code (as collected) | CLS50-A1B2 |
