EMERSON A6220 AMS 6500 Shaft Eccentricity Monitor
- Brand
- EMERSON
- Model
- A6220
- GEARWELL SKU
- GWP-000033819
- Category
- Test & Measurement
Key specifications
- Format
- 3U, 1-slot plug-in module, API 670 compliant, hot swappable
- Outputs
- 0/4-20 mA per channel
- Channels
- 2 (independent)
- Input type
- Eddy current, differential
- Model number
- A6220
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | EMERSON A6220 AMS 6500 Shaft Eccentricity Monitor |
|---|---|
| Brand | EMERSON |
| Model | A6220 |
| Category | Test & Measurement |
| Format | 3U, 1-slot plug-in module, API 670 compliant, hot swappable |
| Outputs | 0/4-20 mA per channel |
| Channels | 2 (independent) |
| Input type | Eddy current, differential |
| Model number | A6220 |
| Product line | AMS 6500 / CSI 6500 machinery protection (Emerson, formerly epro) |
| Sensor inputs | 6422, 6423, 6424, 6425 |
| Measuring range | 0-400 to 0-8000 mV peak (adjustable) |
| Input voltage range | -1 to 23 VDC |
| Input frequency range | 0.017 - 70 (102 - 4200 rpm) Hz |
