Dynapar HSD351024PA7 HSD35 Heavy Duty Hollow Shaft Encoder
- Brand
- Dynapar
- Model
- HSD351024PA7
- GEARWELL SKU
- GWP-000021516
- Category
- Encoders & Position
Key specifications
- Fixing
- Rod tether kit, AC motor fan cover with T-bolt
- Bore size
- 25 mm
- Brand note
- Seller listed under HENGSTLER (Dynapar group brand)
- Protection
- IP67
- Resolution
- 1024 PPR
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Dynapar HSD351024PA7 HSD35 Heavy Duty Hollow Shaft Encoder |
|---|---|
| Brand | Dynapar |
| Model | HSD351024PA7 |
| Category | Encoders & Position |
| Fixing | Rod tether kit, AC motor fan cover with T-bolt |
| Bore size | 25 mm |
| Brand note | Seller listed under HENGSTLER (Dynapar group brand) |
| Protection | IP67 |
| Resolution | 1024 PPR |
| Termination | 10 Pin latching industrial connector |
| Input voltage | 5-26 VDC |
| Maximum speed | 6000 rpm |
| Incremental signals | A, A', B, B', Z, Z' |
| Operating temperature | -40 to +85 °C |
