DELIXI JJ1B-30KW 380V JJ1B Autotransformer Starter Cabinet
- Brand
- DELIXI
- Model
- JJ1B-30KW 380V
- GEARWELL SKU
- GWP-000021239
- Category
- Contactors & Starters
Key specifications
- Seller code
- JJ1B30
- Rated voltage
- AC 380 V
- Type designation
- JJ1B-30
- Outline dimensions
- 530 x 350 x 1000 (A x B x H) mm
- Controlled motor power
- 30 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI JJ1B-30KW 380V JJ1B Autotransformer Starter Cabinet |
|---|---|
| Brand | DELIXI |
| Model | JJ1B-30KW 380V |
| Category | Contactors & Starters |
| Seller code | JJ1B30 |
| Rated voltage | AC 380 V |
| Type designation | JJ1B-30 |
| Outline dimensions | 530 x 350 x 1000 (A x B x H) mm |
| Controlled motor power | 30 kW |
| Standard / certification | GB 14048.4 / CCC |
| Max. total starting time | 40 s |
| Working current (reference) | 57 A |
| MCCB release rated current | 63 A |
| Motor protector setting (reference) | 57 A |
| Current changeover setting (reference) | 5.7 A |
