DELIXI JJ1B-160KW 380V JJ1B Autotransformer Starter Cabinet
- Brand
- DELIXI
- Model
- JJ1B-160KW 380V
- GEARWELL SKU
- GWP-000021238
- Category
- Contactors & Starters
Key specifications
- Seller code
- JJ1B160
- Rated voltage
- AC 380 V
- Type designation
- JJ1B-160
- Outline dimensions
- 670 x 580 x 1800 (A x B x H) mm
- Controlled motor power
- 160 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI JJ1B-160KW 380V JJ1B Autotransformer Starter Cabinet |
|---|---|
| Brand | DELIXI |
| Model | JJ1B-160KW 380V |
| Category | Contactors & Starters |
| Seller code | JJ1B160 |
| Rated voltage | AC 380 V |
| Type designation | JJ1B-160 |
| Outline dimensions | 670 x 580 x 1800 (A x B x H) mm |
| Controlled motor power | 160 kW |
| Standard / certification | GB 14048.4 / CCC |
| Max. total starting time | 90 s |
| Working current (reference) | 300 A |
| MCCB release rated current | 400 A |
| Motor protector setting (reference) | 2.5 A |
| Current changeover setting (reference) | 3.8 A |
