DELIXI CDJ1-Z6 22KW CDJ1 Device-Type Motor Soft Starter
- Brand
- DELIXI
- Model
- CDJ1-Z6 22KW
- GEARWELL SKU
- GWP-000021125
- Category
- Contactors & Starters
Key specifications
- Weight
- 9 kg
- Version
- CDJ1-Z device type
- Seller code
- CDJ1Z622
- Rated current
- 45 A
- Applicable motor
- Three-phase squirrel-cage induction motor
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDJ1-Z6 22KW CDJ1 Device-Type Motor Soft Starter |
|---|---|
| Brand | DELIXI |
| Model | CDJ1-Z6 22KW |
| Category | Contactors & Starters |
| Weight | 9 kg |
| Version | CDJ1-Z device type |
| Seller code | CDJ1Z622 |
| Rated current | 45 A |
| Applicable motor | Three-phase squirrel-cage induction motor |
| Dimensions (H×W×D) | 330 × 200 × 160 mm |
| Rated motor power | 22 kW |
| Rated supply voltage | AC 380 V, 50 Hz ±10% |
| Utilization category | AC-53b |
| Code suffix "Z6" (digit 6) | as collected; not listed in the official model-number table |
