DANFOSS 060L1112 KP69 KP Series Thermostat Temperature Switch
- Brand
- DANFOSS
- Model
- 060L1112
- GEARWELL SKU
- GWP-000022406
- Category
- Pressure, Flow & Temperature
Key specifications
- Enclosure
- IP30
- Sensor type
- Remote air coil
- Contact rating
- AC15=10 A, 400 V; AC1=16 A, 400 V; AC3=16 A, 400 V; DC13=12 W, 220 V; LR=112 A, 400 V
- Sensor size (Ø x L)
- 9.5 x 70 mm
- Contact function
- SPDT
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DANFOSS 060L1112 KP69 KP Series Thermostat Temperature Switch |
|---|---|
| Brand | DANFOSS |
| Model | 060L1112 |
| Category | Pressure, Flow & Temperature |
| Enclosure | IP30 |
| Sensor type | Remote air coil |
| Contact rating | AC15=10 A, 400 V; AC1=16 A, 400 V; AC3=16 A, 400 V; DC13=12 W, 220 V; LR=112 A, 400 V |
| Sensor size (Ø x L) | 9.5 x 70 mm |
| Contact function | SPDT |
| Type designation | KP69 |
| Temperature range | -5 ... 35 °C |
| Danfoss code number | 060L111266 (collected as 060L1112) |
| Capillary tube length | 2000 mm |
| Differential (at min. range setting) | 4.5 ... 25 °C |
